304 316L Stainless steel welded capillary tubing
Material: SS 304,SS 316L
OD: 0.2-16mm
Length<=12m or as per customer request
MOQ: >=10kgs
Product name: 304 316L Stainless steel welded capillary tubing
Standard: ASTM A269
Material grade: SS 304, SS 316L,
Outer diameter: 0.2mm ~ 16mm
Wall thickness: 0.05mm ~ 3mm
Length: ≤12000mm or as per customer request
Tolerance:
a)Outer diameter: +-0.01mm~+-0.1mm
b)Wall thickness: +-10% or as customer’s request
c)Length: ≤ +-10mm
Surface: Satin,hairline,polish,mirror surface,pickling
Application: Decoration,medical,industry,etc..
Packing: Plastic bag,woven packing,carton,wooden case(please send details packing to us if you have special requests)
MOQ: 10kgs for stock size, 50kgs for customized sizes
Payment term: TT
Element | 202 | 316 | S32750 | |||||||||||||
≤0.15 | ≤0.08 | ≤0.030 | Si | ≤1.00 | ≤1.00 | ≤0.80 | ||||||||||
5.5-7.5 | ≤2.00 | ≤2.00 | P | ≤0.060 | ≤0.045 | ≤0.035 | ||||||||||
≤0.030 | ≤0.030 | ≤0.020 | Cr | 17-19 | 16-18 | 21-23 | ||||||||||
3.5-5.5 | 42958 | 4.5-6.5 | Mo |
| 2.0-3.0 | 3.0-5.0 | ||||||||||
≤0.25 |
| 0.08-0.2 | Cu |
|
| ≤0.50 | ||||||||||
Material Item | 202 | 316 | Tensile Strength (MPa) | ≥620 | ≥515 | Yield Strength (MPa) | ≥310 | ≥205 | Elongation (%) | ≥35 | ≥35 | Hardness (HV) | ≤230 | ≤200 | <span style="font-family:" font-size:14px;"="">≤303 | |
